Cone-Pulley-Type-Lathe-Machine

Specification

LCP-4.5

LCP-6.0

BED

 Bed Type

 2v & 2 Flat

 2v & 2 Flat

 Bed Lathe

 1372 (4’6″)

 1825(6′)

 Bed Width

 275(11″)

 275(11″)

 Gap Length

 125mm

 125mm

 Gap Length in front of faceplate

 110mm

 110mm

CAPACITY

 Height of center

 200 (8.0″)

 200 (8.0″)

 Swing over head

 350 MM

 350 MM

 Swing over cross slide

 200 MM

 200 MM

 Swinging gap

 500 MM

 500 MM

 Admit between center

 480 MM

 940 MM

 Movement of cross slide

 200 MM

 200 MM

 movement of compound slide

 110mm

 110mm

MAIN SPINDLE

 Spindle nose

 75 MM Threaded Type

 75 MM Threaded Type

 Taper bore in spindle sleeve

 MT-4

 MT-4

 Spindle bore

 50(2″)

 50(2″)

TAIL STOCK

 Quill data

 50 MM

 50 MM

 Taper in quill

 MT-4

 MT-4

 Quill travel

 170mm

 17mm

SPEED

 No.of spindle speed

 8

 8

 RPM (Low / High)

 45 – 750

 45 – 750

THREADS

 Metric thread

 13(1 to 6 mm)

 13(1 to 6 mm)

 English thread

 19(2 to 24 TPI)

 19(2 to 24 TPI)

 Lead Screw

 32 mm * 4 TPI

 32 mm * 4 TPI

ELECTRICALS

 Motor Power

 1.5kw / 2 HP

 1.5kw / 2 HP

 Motor Power

 B – 52

 B – 52
