MODEL

VM1GM

VM2GM

TABLE

Working surface

1200x300

1350x300

Swivel

±45°

±45°

T-Slot Nos./Size

3/17

3/17

T-Slot Centre

70

70

Table Loading Capacity (kgms)

200

300

X-Longitudinal Travel (Auto)

550

700

Y-Cross travel (Manual)

180

220

Z-Vertical Travel (Manual)

300

410

FEEDS

No. of Feeds

Variable

Variable

X Axis Feeds/min.

25-100

25-100

SPINDLE

Spindle Taper

ISO 40

ISO 40

No. of Spindle Speeds (On Selection)

9

9

Range of Spindle Speeds (RPM)

45-700

45-700

Distance from Spindle to Table

325

410

Distance Spindle Centre to Col.

250

300

Vertical Head Tilt

±90°

±90°

Manual Quill Travel

90

90

ELECTRICAL

Main Motor

3 HP

3 HP

Feed Motor

1.5 HP

1.5 HP

Coolant Pump

0.1 HP

0.1 HP

DIMENSIONS (APPROX.)

Weight

1500

1800
